Function & Character:
1. Frequency auto-controlling system with high automation while the machine can be also upgraded as per customers' reasonable requirement.
2. Under European CE standard designing, passed the CE certificate, Electric parts under CE or UL quality certification, with safety protection unit, such as, safety door and emergency stop and so on.
3. Most of the spare parts are under numerical control precisely processing, Key mechanical parts are under CNC processing, Main outsourcing parts are World famous brand.
4. Operating interface is the industry PLC with humanistic designing and optional collection for production record.
5. It is workable to mount the camera monitoring system, which can conduct on-line size checking, location inspecting, missing inspecting and stain spot scanning and so on.
6. Other optional functions can be chosen by customers' requirement:
A)Jumbo roll auto splicing servo control;
B)Jumbo roll auto splicing converter control;
C)Jumbo roll semi-automatic unwinding system;

Main Technical Parameter:
1. Outputted products from this machine: Cotton core type and ultra-thin type fast-easy package panty liner;
2. Designed speed: Vertical output 1000PCS/min, horizontal output 2000PCS/min;
3. Production speed: Vertical output 900-1000PCS/min, horizontal output 1600-2000PCS/min,
4. Overall size of equipment: 15m (L)*4m (W)*3m (H).
5. Machine power: Approx 160KW(380V, 50Hz);
6. Weight of equipment: About 28 T.
